General Features

The built-in subwoofer delivers deep bass. There’s no need for another box and extra cables around your living room.

Delivers powerful sound that enhances any movie experience.

Stream and enjoy all your music wirelessly from any mobile device.

The one cable HDMI ARC connection allows for the simplest set-up and a hassle-free user experience.

What’s in the box:

  • Soundbar
  • Remote control with batteries
  • Power cables (up to 4pcs depending on region SKUs)
  • HDMI cable
  • Wall-mount bracket kit with screws
  • Quick start guide
  • Warranty card
  • Safety sheet

Key Specifications

  • Power supply: 100 – 240VAC, ~ 50/60Hz
  • Total speaker power output (Max. @THD 1%): 110W
  • Soundbar power output (Max. @THD 1%): 2 x 27W + 56W
  • Subwoofer power output (Max. @THD 1%): N/A
  • Soundbar transducer: 2 x 2.25″ full range driver + 2 x 2.5″ woofer
  • Operating temperature: 0°C – 45°C
  • Video HDMI Video output (With Audio return channel): 1
  • HDMI HDCP version: 1.4
  • Audio Max SPL: 82dBFrequency response: 40Hz – 20kHz
  • Audio inputs: 1 Optical, Bluetooth (USB is for Service only.)
  • USB (For Service only)
  • USB port: Type A
  • USB rating: 5VDC/0.5A
  • Supporting file format: mp3, wav
  • MP3 Codec: MPEG 1 Layer 2/3; MPEG 2 Layer 3; MPEG 2.5 Layer 3
  • MP3 sampling rate: 16kHz – 48kHz
  • MP3 bitrate: 80kbps – 320kbps; 80kbps – 160kbps (MPEG 2.5 Layer 3)
  • WAV sample rate: 16kHz – 48kHz
  • WAV bitrate: Up to 3000kbps
  • Wireless Bluetooth version: 4.2
  • Bluetooth profile: A2DP V1.3/AVRCP V1.5
  • Bluetooth frequency range: 2402MHz – 2480MHz
  • Bluetooth max. transmitting power: <0dbm (EIRP)
  • Modulation type: GFSK, π/4 DQPSK
  • Soundbar dimensions (W x H x D): 950 x 90 x 55(mm) / 37.4″ x 3.5″ x 2.1″
  • Soundbar weight: 2.6kg
  • Packaging dimensions (W x H x D): 1100 x 125 x 95(mm) / 43.3″ x 4.9″ x 3.7″
  • Packaging weight (Gross weight): 3.1kg

Awards

Design Award 2020 Best Product 2019-2020 What Hi Fi

JBL Cinema SB 110

| /
