General Features

JBL MultiBeamTM technology brings the ultimate cinematic experience to your home. No extra speakers or wires are needed.

With 550 Watts of system output power, experience your movies and music like never before. Immersive, powerful sound to match your viewing pleasure.

Punchy, precise bass from a mighty 10" wireless subwoofer brings the action to action movies, and ensures any soundtrack sounds epic.

The best 4K video resolution deserves the best sound to go with it. Your TV and the JBL Bar 5.1 Surround are the ultimate power couple.

Built-in WiFi and compatibility with Chromecast and Airplay 2 means you can stream your all favourite online content with amazing sound, with a simple finger tap.

Not in the mood for a film? No problem. With the JBL Bar 5.1 Surround, you can also enjoy wireless music streaming via Bluetooth from your mobile or tablet.

What’s in the box:

  • Soundbar
  • Wireless subwoofer
  • Remote control with batteries
  • Power cords (up to 8pcs depending on region SKUs) HDMI cable
  • Wall-mount bracket kit with screws
  • Quick start guide
  • Warranty card
  • Safety sheet

Key Specifications

  • Model: Bar 5.1 CNTR (Soundbar Unit),
  • Bar 5.1 SUB (Subwoofer Unit)
  • Power supply: 100 – 240V AC, ~ 50/60Hz
  • Total speaker power output (Max. @THD 1%): 550W Soundbar output power (Max. @THD 1%): 5 x 50W Subwoofer output power (Max. @THD 1%): 300W Soundbar transducer: 5 x racetrack drivers +
  • 2 x 1.25" side-firing tweeters Subwoofer transducer: 10" Operating temperature: 0°C – 45°C
  • HDMI Video input: 1
  • HDMI Video output (With Audio return channel): 1 HDMI HDCP version: 2.3
  • Max SPL: 103dB
  • Audio inputs: 1 Optical, Bluetooth, USB (USB playback is available in US version. For other versions, USB is for Service only.)
  • USB port: Type A
  • USB rating: 5V DC, 0.5A
  • Supporting file format: mp3
  • MP3 Codec: MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3
  • MP3 sampling rate: 16kHz – 48kHz MP3 bitrate: 80kbps – 320kbps
  • Bluetooth version: 4.2
  • Bluetooth profile: A2DP V1.2, AVRCP V1.5
  • Bluetooth frequency range: 2402MHz – 2480MHz Bluetooth Max. transmitting power: <11dBm (EIRP) Modulation Type: GFSK, π/4 DQPSK, 8DPSK
  • Wi-Fi network: IEEE 802.11 a/b/g/n/ac (2.4GHz/5GHz) 2.4G Wi-Fi frequency range: 2412 – 2472MHz
  • (2.4GHz ISM Band, USA 11 Channels, Europe and others 13 Channels)
  • 2.4G Wi-Fi Max. transmitting power: <20dBm
  • Modulation Type: DBPSK, DQPSK, CCK, QPSK, BPSK, 16QAM, 64QAM
  • 5G Wi-Fi frequency range: 5.15 – 5.35GHz,
  • 5.470 – 5.725GHz, 5.725 – 5.825GHz
  • 5G Wi-Fi Max. transmitting power: <22dBm
  • Modulation Type: QPSK, BPSK, 16QAM, 64QAM, 256QAM 5G Wireless frequency range: 5736.35 – 5820.35MHz 5G Max. transmitting power: <9dBm (EIRP)
  • Modulation Type: π/4 DQPSK
  • Dimensions(WxHxD):1018x58x100mm/
  • 40.1" x 2.3" x 3.9" (Soundbar); 305 x 440 x 305mm / 12.0" x 17.3" x 12.0" (Subwoofer)
  • Weight: 2.85kg (Soundbar); 10.62kg (Subwoofer)
  • BAR 5.1 SURROUND is in compliance with European Commission Regulation (EC) No 1275/2008 and (EU) No 801/2013.
  • Off mode: N/A
  • Network standby: <2.0W Time to standby: <10 minutes

Awards

Design Award 2020 Best Product 2019-2020 What Hi Fi
