General Features

Fill your whole room with sound. An impressive 300W of total system power puts you in control. Your movies and music have never sounded so good.

JBL Surround Sound instantly brings movies, sports, and music to life. Upgrade to an immersive sound experience for your TV without any extra wires or speakers.

Why just listen to the bass when you can experience it? The 6.5" wireless subwoofer delivers deep, thrilling sound.

Get the popcorn ready. Built-in Dolby Digital gives you an authentic cinematic experience in your home.

Not in the mood for a film? No problem. With the JBL Bar 2.1 Deep Bass, you can also enjoy wireless music streaming via Bluetooth from your mobile or tablet.

Connecting JBL Surround Sound could not be easier. The HDMI or Optical cable connection is super simple to set up and use.

What’s in the box:

  • Soundbar
  • Wireless subwoofer
  • Remote control with batteries
  • Power cords (up to 8pcs depending on region SKUs)
  • HDMI cable
  • Wall-mount bracket kit with screws Quick start guide
  • Warranty card
  • Safety sheet

Key Specifications

  • Model: Bar 2.1 Deep Bass CNTR (Soundbar Unit), Bar 2.1 Deep Bass SUB (Subwoofer Unit)
  • Power supply: 100 – 240V AC, ~ 50/60Hz
  • Total speaker power output (Max. @THD 1%): 300W
  • Output power (Max. @THD 1%):
  • 2 x 50W (Soundbar); 200W (Subwoofer)
  • Transducer: 4 x race-track drivers + 2 x 1" tweeter (Soundbar); 6.5" (Subwoofer)
  • Soundbar and Subwoofer standby power: <0.5W
  • Operating temperature: 0°C – 45°C
  • HDMI Video input: 1
  • HDMI Video output (With Audio return channel): 1
  • HDMI version: 1.4
  • Frequency response: 40Hz – 20kHz
  • Audio inputs: 1 Optical, Bluetooth, USB (USB playback is available in US version. For other versions, USB is for service only.)
  • USB port: Type A
  • USB rating: 5V DC/0.5A
  • Supporting file format: mp3, wav
  • MP3 Codec: MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3
  • MP3 sampling rate: 16kHz – 48kHz
  • MP3 bitrate: 80kbps – 320kbps
  • WAV sample rate: 16kHz – 48kHz
  • WAV bitrate: Up to 3000kbps
  • Bluetooth version: 4.2
  • Bluetooth profile: A2DP V1.3, AVRCP V1.5
  • Bluetooth frequency range: 2402MHz–2480MHz
  • Bluetooth Max. transmitting power: <10dBm (EIRP)
  • Modulation type: GFSK, π/4 DQPSK, 8DPSK
  • 5G Wireless frequency range: 5736.35 – 5820.35MHz
  • 5G Max. transmitting power: <9dBm (EIRP)
  • Modulation Type: π/4 DQPSK
  • Dimensions (W x H x D): 965 x 58 x 85 (mm) / 38" x 2.28" x 3.35" (Soundbar);
  • 240 x 240 x 379 (mm) / 8.9" x 8.9" x 14.6" (Subwoofer)
  • Weight: 2.16kg (Soundbar); 5.67kg (Subwoofer)
  • Packaging dimensions (W x H x D): 1045 x 310 x 405mm
  • Packaging weight (Gross weight): 10.4kg

Awards

Design Award 2020 Best Product 2019-2020 What Hi Fi
